Which words are Reserved in ProcessModel?

processmodel reserved words

What reserved words are used by the system that cannot be used to name entities, activities, variables, attributes, scenario parameters, etc.

The following words are reserved by the system and cannot be used as variable names, attributes, or scenario parameters. using these reserved words will result in a simulation error. Rather than use a reserved word directly an underscore can be applied as a prefix or a suffix to make the word usable as one of the names variables, attributes, or scenario parameters.

Note: If a reserved word is used in the action logic, ProcessModel will produce a message before simulation starts, the message will say * is a reserved word.

accum
activate
all
alt
and
animate
arraydims( )
arraydimsize( )
as
b
backup
begin
bi
board
break
breakblk
bvatime
by
calday( )
caldom( )
calhour( )
calmin( )
calmonth( )
calyear( )
cancel
cap( )
case
char( )
claim
clock
clock( )
close
combine
condition
cont
contents
contents( )
convey
cost
create
cyclestart
d2
d3
d4
d5
day
debug
dec
default
dep
dispatch
display
do
dosload
downqty( )
drop
dtdelay( )
dtleft( )
e
else
empty
end
ent
ent( )
entity
entity( )
entries
entries( )
er
exit
exp( )
fifo
first
for
forlocation( )
format
forresource( )
free
freecap
freecap( )
freeunits
full
g
geo
get
getcost
getresrate
goto
graphic
group
groupqty( )
hide
hr
id
if
iff
ig
in
inc
incentcost
incloccost
increscost
inf
infinite
install labels
int
join
jointly
jointlyget
keep
l
labels
last
lifo
ln
ln( )
load
loc( )
location
location( )
locstate( )
log
lu
maparr
match
min
mod
most
move
move for
move on
move with
ms
n
name
newgraphic
newname
next
next( )
off
or
order
ot
ownedresource
ownedresource( )
p
p5
p6
pause
percent
percentage
percentop( )
percentutil( )
pick
preemptedres
preemptor
priority
prompt
queue
rand
rand( )
random
read
real
real( )
recently
rename
report
res( )
reserve
reset
reset stats
resource
resourceunit( )
resqty
return
round
round( )
route
sec
send
setrate
show
skip
snapshot
sound
split
split as
sqrt
sqrt( )
stop
t
take
then
threadnum
time
timeleft
timesused( )
timeused
to
trace
trunc
trunc( )
turn
u
ungroup
units
units( )
unload
until
up
use
variable
vatime
view
w
wait
warmup
while
wk
write
writeline
xsub
xwrite
